Selection Considerations Chapter 1
Single Phase/
Phase Loss Fault
(s) (s)
Line Sync Fault (s) (s)
Input Overcurrent Fault (s) (s)
Overload Fault (s) (s)
IGBT Over temp Fault (s) (s)
LCL Filter Over temp Fault (s) (s)
DC Bus Over Voltage Fault (s) (s)
DC Bus Under Voltage (s) (s)
AC Line Fuse Blown Fault — (s)
DC Bus Fuse Blown Fault — (s)
Precharge Fault — (s)
AC Input Over Voltage Fault — (s)
Cooling Fan Fault/Alarm (s) (s)
Transient Voltage Suppressor
(TVSS) Fail Alarm
—(s)
DC Bus Conditioner Fault (o) external device (s)
Table 14 - User Interface
Description PowerFlex 700AFE Bus Supply PowerFlex 755TM Bus Supply
Cat No. 20Y… Cat. No. 20J…
Local HIM (o) 20-HIM-A3, 20-HIM-A6 (o) 20-HIM-A6
Remote HIM (o) 20-HIM-C3S, 20-HIM-C6S (o) 20-HIM-C6S
DriveExplorer/DriveExecutive (s) —
Connected Components
Workbench (CCW)
(s) (s)
Studio5000/RSLogix 5000 (s) with communication option (s)
Digital Inputs (s) 6, 24V DC
• inputs 1…5 used for door
controls
• input 6 used for Hardware Enable
(o) 20-750 series 24V DC and 115V AC I/O
modules;
3…6, depending on option module
chosen
Digital Outputs (s) 2, form C relay, outputs 1, 2 used
for door-mounted operator devices.
• Relay 240V AC/30V DC 1200VA,
150 W resistive or, 240V AC/
30V DC, 840VA, 105 W inductive.
(o) 20-750 series 24V DC and 115V AC I/O
modules;
2...3, relay or transistor depending on
option module chosen.
• Relay NO, 240V AC/24V DC, 2 A
resistive/general purpose inductive.
• Relay NC, 240V AC/24V DC, 2 A resistive.
• Transistor, 24V DC, 1 A max resistive.
Table 13 - Protection Features (Continued)
Description PowerFlex 700AFE Bus Supply PowerFlex 755TM Bus Supply
Cat No. 20Y… Cat. No. 20J…
To Next Page
