Allen-Bradley PowerFlex 755TM Migration Guide

Rockwell Automation Publication 750-RM003A-EN-P - April 2018 73
Bus Supply Hardware and Parameter Conversion Chapter 2
Figure 18 - PowerFlex 700AFE Bus Supply, Frame 10, IP20 2500 MCC, Sample Wiring Diagram
3Phase AC
Power Source
DC Output
CMC
DC
VFD ENB
+
L1 L2 L3 PE
DC + DC - PE
To Control Pod I/O and Fiber Interface Board
Door
Fans
F2
AFE Power
Structure
LCL Filter
K1
3ph Rectier
K6
Precharge
F5
R6
Precharge
F1
Q0
T4
1500VA
F4
230VAC
K1
120VAC
DC
P/S
F11
F3
Set T4 primary tap to
match AC line voltage
Internal Fan
24VDC
P/S
T10
24VDC
CM CAP
6
Jumpers
S6
REM MAN AUTO
S10
OFF ON START
S11
RESET
FAULT
READY
VFD Enb COM VFD Enb +24V Line Volt Line Volt Line Volt Line Volt
X3
Rem START Rem ON PERM Rem RESET
57 60 58 61 63 64 65 66
400 480 600 690
F6
Door Operator
Devices
ASIC PCB
Fiber
Cables
( 7 )
Control
Relays
H1~H7
REM START
REM ON
REM RESET
