Publication 2711-UM014B-EN-P
B-16 Messages, Codes and Self-Test Numbers
Note: You may not see all of these test numbers during a powerup.
If a test fails, the terminal displays:
ERROR! FEHLER! ERREUR! ERRORE!
The following test numbers appear only if a problem occurs.
The table below shows fault conditions that may occur during
powerup.
30 Watchdog test
31 Stuck key test
32 Real time clock test
33 LCD RAM failed
34 Performed CRC extended firmware check
Test Number Indicates
40 No executable code to run after boot
50 Wrong memory card format
60 CPU could not execute code
Fault Indicator Indicates
Solid Red Static RAM Test failed. Contact technical support.
Blinking Red
(6 times per second)
Checksum test on boot code failed. Contact technical support.
Blinking Red
(5 seconds on/5 seconds off)
Boot code is incorrect for terminal type (touch screen or keypad).
Contact technical support.
Test Number Indicates
