SLC 500™ Programmable Controller Rack Interconnect Cables
3
Figure 1
Two racks linked with Catalog No. 1746-C7 Cable
Catalog number 1746-C9
Catalog number 1746-C9
Two racks linked with Catalog No. 1746-C7 Cable
Catalog No. 1746-C9
Tab
Connecto
r
“Key”
Tab
Removing cable (with connector and “key”)
