INITIAL ASSEMBLY INSTRUCTIONS
2. Remove the preassembled downrod clip (HH) and
downrod pin (II) from the bottom of the downrod (C).
Retain these two parts for later.
Hardware Used
HH
Downrod Clip x 1
II
Downrod Pin x 1
2
C
II
HH
3. Loosen the two preassembled downrod support
set screws (JJ) on the motor (A). Route the black,
blue, and white wires from the motor (A) through the
downrod (C).
Hardware Used
JJ
Downrod Support
Set Screw
x 2
3
C
A
JJ
JJ
