allen MP235 - Drive Belt

3-4
SECTION 3
SERVICE
053383; 11/10
3.3
Drive Belt
3.3.0 Drive Belt Maintenance
The drive belts MUST be free from oil and
foreign contaminants to prolong life.
3.3.1 To Replace The Drive Belt:
1) Place the trowel on a flat, level surface with the blades pitched flat.
2) Disconnect the battery. Refer to Figure 3.3.1.
3) Remove the clutch cover. Refer to Figure 3.3.2.
5) Remove tap bolt to remove driver pulley.
6) Loosen the set screws in the flex u-joint.
7) Slide the u-joint apart so belt will slide through.
8) Replace belt using part #051332.
9) Repeat steps 7 through 2 in reverse order.
