allen MP235 - Right Hand Control Lever Adjust

3-11
053383; 11/10
SECTION 3
SERVICE
3.5, continued
Right Hand Control Lever Adjust
FIGURE 3.5.1
“V” FORM ORIENTATION
FIGURE 3.5.2
RIGHT HAND CONTROL ADJUSTMENT
JOYSTICK LOCATIONS
“V” FORM
[C]
LINKAGE
LOWER CONTROL
ARM
[D]
There should be a
10” gap at the top
of the joysticks.
