053383 - 07/2017
4-2
SECTION 4
PARTS
Factory Service Information
This section contains the illustrated drawings and parts list for help in identifying and/or ordering
replacement parts for your machine. Follow the instructions in the front section of this manual
“Ordering Parts” when ordering replacement parts to insure prompt and accurate delivery.
The Right Hand (RH) and/or Left Hand (LH) orientations are dened from the operator’s view of
sitting on machine (SOM).
All set screws have blue (LOC-TITE™) applied at the
factory. If set screw is removed or loosened for any
reason re-apply blue (LOC-TITE™).
All grease ttings are capped with CAP PLUG GC-5
(AEC PN 015692) to protect the tting. If cap becomes
missing or damaged replace it as soon as possible.
Anti-Seize is applied at the factory to all drive line coupling,
gearbox main and counter shafts and pitch control threaded rod
assemblies. If these parts are disassembled re-apply a light
coat of a graphite based anti-seize.
