ITEM PART # DESCRIPTION QTY
1 10005 FSTN, HHCS 1/4-20 X 1-1/2 GR 8 2
2 10035 FSTN, HHCS 3/8-16 X 3/4 4
3 10036 FSTN, HHCS 3/8-16 X 1 4
4 10051 FSTN, NUT 1/2-20 JAM HEX 5
5 10085 FSTN, FW 1/2 2
6 10091 FSTN, LW 3/8 8
7 10464 FSTN, NUT NYLOK 3/8-16 6
8 10711 CLIP, .125x2-9/16 HITCH PIN 2
9 17751 FSTN, FW HARD A325 3/8 8
10 19900 END, 1/2 FEMALE ROD 3
11 20542 FSTN, NUT STOVER LOCK 1/4-20 2
12 26267 FSTN, SHLDR 1/2” X 1” LONG 6
13 26447 NUT, 3/4-10 SELFLOCK THIN HEX 3
14 37140 BOLT, 1/2-20x1-1/2 GR 5 HHC 1
15 37481 WIRE, 18 GA. 2 CONDUCTOR 6
16 37798 FSTN, HHCS 1/2-13 X 1 1/2 GR8 3
17 40208 FSTN, 1/2-13 STOVER NUT 3
18 47480 BOLT, 1/2-20x1-1/4 YZ GR 8 HEXHD CAP 2
19 48354 GRIP, SAT 3 Ø1 BLACK HANDLE 1
20 48561 BEARING ASSEMBLY F/ ROTOR MOUNT X1 4
21 48896 JOYSTICK, STEERING MSP 2
22 48909 SWITCH, PUSH BUTTON 1
23 48910 BRG, Ø5/8 NYL FLNG SLEEVE 1
24 48928 SHIM, 3/4 ID X 1-1/8 OD WEAR 2
25 48929 BEARING, Ø3/4 ID PLASTIC FLANGE 12
26 48969 WELDMENT, STEERING SHAFT MSP425 1
27 48970 WELDMENT, FULCRUM SHAFT MSP425 1
28 49245 GRIP, MODIFIED HANDLE 1
29 53111 LEVER, STEERING, RH 1
30 53114 LEVER, STEERING, LH 1
31 53115 STEERING TUBE WMNT, RH 1
32 53120 PIVOT ARM F/ STEERING 2
33 53124 STEERING LEVER WMNT 1
34 53160 WELD’T, MAIN FRAME MP235 1
35 53162 ROTOR ASSEMBLY, RH 1
36 53164 ROTOR ASSEMBLY, LH MP235 1
37 53174 SHAFT, 18” LONG STEERING LINKAGE 1
38 53179 PIVOT ROD 1
39 53183 STEERING LINK, SHORT 2
40 221408 ROD, END MALE 1/2” 5
053383 - 07/2017
4-9
SECTION 4
PARTS
4.3 Parts List
Steering System
