ITEM PART # DESCRIPTION QTY
032370 ASSY, PITCH CONTROL
1 015410 SCREW, 1/4-20x3/8 RND HD MACH 2
2 015747 PIN, 3/16x1-3/8 ROLL 1
3 015768 SCREW, 1/4-20x1/4 SCKT HD CAP 2
4 026420 TUBE, PRO PITCH CONTROL 1
5 029812 BUSHING, SLIDE PITCH CONTROL 1
6 029822 SHAFT, PITCH CONTROL 1
7 032115 KNOB, PITCH CONTROL HANDLE 1
8 012710 RACE, BEARING THRUST 2
9 015742 BEARING, FINE PITCH CONTROL 1
10 032157 ASSY, HANDLE 1
11 032191 STOP, PITCH CONTROL HANDLE 1
12 036797 PLUNGER, 1/4-20 BALL 2
13 036914 BUSHING, CABLE ASSY 1
14 100340 BEARING, NAT-1220 THRUST 1
15 026541 CRANK HANDLE & SCREW SHAFT ASY 1
16 012869 FSTN, SHSS 1/4-20 X 3/8 2
17 032377 DECAL, F/ PITCH CONTROL TUBE 1
18 053442 DECAL, ALLEN VERTICAL BRUSHED CHROME 1
053383 - 07/2017
4-13
SECTION 4
PARTS
4.5 Parts List
Pitch Control Assembly
