ITEM PART # DESCRIPTION QTY
053162 ROTOR ASSEMBLY, RH MP235
1 010023 FSTN, HHCS 5/16-18 X 3/4 GR 5 4
2 010024 FSTN, HHCS 5/16-18 X 2 GR 5 4
3 010035 FSTN, HHCS 3/8-16 X 3/4 8
4 010090 FSTN, LW 5/16 8
5 010091 FSTN, LW 3/8 10
6 012612 FSTN, NUT HEX NYLOCK 5/16-18 1
7 015677 RING, Ø7/16 E-STYLE RETAINING 2
8 015678 PIN, YOKE ARM 1
9 015690 WASHER, RETAINING FOR TROWELS 1
10 015692 CAP, Ø1/4 RED GREASE 4
11 015693 PLUG, PLASTIC CAP EC12 1
12 015694 PLUG W-1 RED PLASTIC TAPERD 4
13 015696 KEY, .25x1.25 LG HARD RAD 1
14 015821 CAP, PRESSURE PLATE 1
15 015822 THRUST BEARING 1
16 015824 PLATE, PRO RIDER/WALKER PRESSURE 1
17 015884 SCREW, 3/8-16x1 SCKT CAP 2
18
041695 TROWEL BLADE, FINISH 6 X 14 4
19 020155 SCR, 1/2-13 X 1-1/2 LH SHCS 1
20 024813 SPIDER ASSY, 900-SFC RH-SOM 1
21 026215 YOKE, ARM 1
22 026443 GEARBOX, STD 900/1200 RH (SOM) 1
23 026504 SCR, 5/16-18x1/2xØ3/8x1-1/4 SHLDR 1
24 048561 BEARING ASSEMBLY F/ ROTOR MOUNT X1 2
048559 BAR, BEARING HOUSING ALUM
048560 BEARING, I-GLIDE FLANGE
25 050017 HSNG, GEARBOX 1
26 050020 CROSSHEAD, 4-WAY 1
27 053163 STEERING ARM WMNT 1
053383 - 07/2017
4-21
SECTION 4
PARTS
4.9 Parts List
Right Hand Rotor Assembly
