allen MSP445 - Page 100

4-40
053430; 1/11
4.19 Parts List
Left Hand 20:1 Rotor Assembly
REF
PART NO. DESCRIPTION QTY NOTES
- 064631 ASSY, LH 20:1 ROTOR (1) REF
1 037654 GEARBOX, 20:1 RATIO LH 1
2 029529 VALVE, RELIEF 1/8-27NPT (AIR V) 1
3 040794 ASSY, 1200-5-SHD LH SOM SPIDER 1
4 039686 CAP, SHD PRESSURE PLATE 1
5 039687 PLATE, SHD PRESSURE 1
6 039685 BEARING, THRUST AXIAL BALL EW 1
7 026215 ARM, YOKE 1
8 015678 PIN, YOKE ARM 1
9 015677 RING, Ø7/16 E-STYLE RETAINING 2
10 010513 FITTING, 1/4-28 STR GREASE 1
11 201163 FITTING, 1/8-27 PTF STR GREASE 1
12 015692 CAP, Ø1/4 RED GREASE 7
13 037652 WASHER, HD RETAINING 1
14 015691 SCREW, 1/2-13x1-1/2 RH SKT HD CAP 1
15 015693 PLUG, PLASTIC CAP EC12 1
16 040833 RING, 1200VG SD 5 BL STAB 1
17 025092 BUSHING, 3/8x1/2x5/16 BRONZE 5
18 025091 SCR, 5/16-18x1/2xØ3/8x3/8 SHLDR 5
19 026504 SCR, 5/16-18x1/2xØ3/8x1-1/4 SHLDR 1
20 012612 FSTN, NUT HEX NYLOCK 5/16-18 1
21 028778 BLADE, 8x18 FLAT FINISH GOLD 5
22 010090 WASHER, 5/16 SPLIT LOCK 15
23 010024 BOLT, 5/16-18x2 GR 5 HHCS 15
24 010095 WSHR, Ø5/8 ID ZINC SPLIT LOCK 8
25 020915 SCR, 5/16-11x1-1/2 HHC 4
26 029311 FSTN, HHCS 5/8-11 X 1 3/4 GR 8 YELLOW ZINC 4
27 010091 WSHR, Ø3/8 ID Z-STL SPLIT LOCK 4
28 010036 FSTN, HHCS 3/8-16 X 1 4
29 048966 WLDMNT, 2-WAY CROSSHEAD 1
30 011791 KEY, 1/4 SQ X 1 LG MACHINE 1
31 064632 WLDMNT, CROSSHEAD GEARBOX MOUNT 1
32 064210 STEERING ARM WMNT, LH 1
NOTES:
1. Not shown.
