allen MSP445 - Right Hand Control Lever Adjust

3-11
053430; 01/11
SECTION 3
SERVICE
3.5, continued
Right Hand Control Lever Adjust
FIGURE 3.5.1
“V” FORM ORIENTATION
FIGURE 3.5.2
RIGHT HAND CONTROL ADJUSTMENT
JOY STICK LOCATIONS
“V” FORM
[C]
[D]
LINKAGE
LOWER
CONTROL
ARM
[D]
