allen MSP445 - Left Hand 20:1 Rotor Assembly

4-39
053430; 1/11
4.19 Illustration
Left Hand 20:1 Rotor Assembly
PARTS LIST
U/MQTYDESCRIPTION
PART
NO.
ITEM
1
GEARBOX,
20:1 RATIO LH
0376
54
1
1
VALVE,
RELIEF
1/8-27NPT
(AIR V)
0295
29
2
1
ASSY,
1200-5-SHD
LH SOM
SPIDER
0407
94
3
1
CAP, SHD
PRESSURE
PLATE
0396
86
4
1
PLATE, SHD
PRESSURE
0396
87
5
1
BEARING,
THRUST
AXIAL BALL
EW
0396
85
6
1
ARM, YOKE
0262
15
7
1
PIN, YOKE
ARM
0156
78
8
2
RING,
Ø7/16
E-STYLE
RETAINING
0156
77
9
1
FITTING,
1/4-28 STR
GREASE
0105
13
10
1
FITTING,
1/8-27 PTF
STR GREASE
2011
63
11
7
CAP, Ø1/4
RED GREASE
0156
92
12
1
WASHER, HD
RETAINING
0376
52
13
1
SCREW,
1/2-13x1-1/2
RH SKT HD
CAP
0156
91
14
1
PLUG,
PLASTIC CAP
EC12
0156
93
15
1
RING,
1200VG SD 5
BL STAB
0408
33
16
5
BUSHING,
3/8x1/2x5/16
BRONZE
0250
92
17
5
SCR,
5/16-18x1/2xØ
3/8x3/8
SHLDR
0250
91
18
1
SCR,
5/16-18x1/2xØ
3/8x1-1/4
SHLDR
0265
04
19
1
FSTN, NUT
HEX NYLOCK
5/16-18
0126
12
20
5
BLADE, 8x18
FLAT FINISH
GOLD
0287
78V
21
15
WASHER,
5/16 SPLIT
LOCK
0100
90
22
15
BOLT,
5/16-18x2 GR
5 HHCS
0100
24
23
8
WSHR, Ø5/8
ID ZINC
SPLIT LOCK
0100
95
24
4
SCR,
5/16-11x1-1/2
HHC
0209
15
25
4
FSTN, HHCS
5/8-11 X 1 3/4
GR 8
YELLOW ZINC
0293
11
26
4
WSHR, Ø3/8
ID Z-STL
SPLIT LOCK
0100
91
27
4
FSTN, HHCS
3/8-16 X 1
0100
36
28
1
WLDMNT,
2-WAY
CROSSHEAD
0489
66
29
1
KEY, 1/4 SQ X
1 LG
MACHI
NE
0117
91
30
1WLDMNT,
CROSSHEAD
GEARBOX
MOUNT
0646
32
31
1
STEERING
ARM WMNT,
LH
0642
10
32
29
25
24
31
27
32
2
28
26
9
8
7
19
20
5
11
12
23
22
10
21
15
1
16
13
30
14
3
6
4
