4.18 Parts List
Right Hand 20:1 Rotor Assembly
NOTES:
1. Not shown.
REF
PART NO. DESCRIPTION QTY NOTES
- 048957 ASSY, RH 20:1 ROTOR (1) REF
1 037655 GEARBOX, 20:1 RATIO RH 1
2 029529 VALVE, RELIEF 1/8-27 NPT 1
3 040795 ASSY, 5-SHD RH SOM SPIDER 1
4 048881 MNT, CROSSHEAD GEARBOX 1
5 039686 CAP, SHD PRESSURE PLATE 1
6 039687 PLATE, SHD PRESSURE 1
7 039685 BEARING, THRUST AXIAL BAL EW 1
8 026215 ARM, YOKE 1
9 015678 PIN, YOKE ARM 1
10 015677 RING, Ø7/16 E-STYLE RETAINING 2
11 015696 KEY, .25x1.25 LG HARD RAD 1
12 010513 FITTING, 1/4-28 NPT STR GREASE 1
13 201163 FITTING, 1/8-27 PTF STR GREASE 1
14 015692 CAP, Ø1/4 RED GREASE 7
15 037652 WASHER, HD RETAINING 1
16 020155 FSTN, SHCS 1/2-13 X 1-1/2 LH 1
17 015693 PLUG, PLASTIC CAP EC12 1
18 040833 RING, 5 BLADE STABILIZER 1
19 025092 BUSHING, 3/8x1/2x5/19 BRONZE 5
20 025091 SCREW, 5/16-18x1/2xØ3/8x3/8 SHOULDER 5
21 026504 SCREW, 5/16-18x1/2xØ3/8x1-1/4 SHOULDER 1
22 012612 NUT, 5/16-18 NYLOCK HEX 1
23 028778 BLADE, 8x18 FLAT FINISH GOLD 5
24 010090 WASHER, SPLIT LOCK 15
25 010024 SCREW, 5/16-18x2 GRADE 5 HEX HD CAP 15
26 048875 ARM, RIGHT STEERING 1
27 010095 WASHER, Ø5/16 ID ZINC SPLIT LOCK 8
28 020915 SCREW, 5/16-11x1-1/2 HEX HD CAP 4
29 019969 SCREW, 5/16x1-3/4 HEX HD CAP 4
30 010091 WASHER, Ø3/8 ID ZINC SPLIT LOCK 4
31 010036 SCREW, 3/8-16x1 HEX HD CAP 4
32 048964 CROSSHEAD, 2-WAY 1
33 048559 BAR, BEARING HOUSING ALUM 2
34 048560 BEARING, I-GLIDE FLANGED T500 2
