allen MSP445 - Control Lever Adjustment

3-8
SECTION 3
SERVICE
053430; 01/11
3.4
Control Lever Adjustment
3.4 Control Lever Adjustment Procedure
Be sure that the trowel is on a level surface. The control levers should line up evenly.
If levers appear out of adjustment they can be re-adjusted forward or backwards as
follows:
Trowel must be placed on flat level
surface that
fully supports the blades on both rotors.
1) Remove bolts and nuts [A].
2) Remove jam nuts [B].
3) Extend linkage to adjust control levers backward.
4) Shorten linkage to adjust linkage control levers forward.
5) After levers have been adjusted to the desired position, reassemble bolts
and nuts [A] and tighten jam nuts [B].
