4.21 Parts List
Left Hand Spider Assembly
NOTES:
1. Not shown.
REF
PART NO. DESCRIPTION QTY NOTES
- 040794 ASSY, LEFT HAND SPIDER (1) REF
1 040698 SPIDER, RH 5 BOSS CW ROT 46-48 1
2 033034 LEVER, LIFT SD UNIVERSAL 5
3 040700 ARM, 5 BOSS SPIDER ASSY TROWEL 5
4 040792 CLIP, 46-48 UNIV SPIDER SPRING 5
5 015683 BOLT, 3/8-16x7/8 DOG POINT HEX HD CAP 5
6 015686 SCREW, 3/8-16x1 SQ HHS 5
7 024755 FITTING, 1/8-27 NPT 45° GREASE 5
8 015682 WASHER, 3/8 EXTERNAL TOOTH LOCK 5
9 028216 BOLT, 1/2-13x1-1/2 GR 8 CARRIAGE 5
10 010050 NUT, 1/2-13 JAM HEX 5
11 015684 NUT, 3/8-16 JAM HEX 5
