4.23 Parts List
LH 20:1 Super Heavy Duty Gearbox
REF
PART NO. DESCRIPTION QTY NOTES
- 037654 GEARBOX, LH SUPER HEAVY DUTY (1) REF
1 029143 CASE, SHD GEARBOX 1
2 029145 SHAFT, COUNTER RH SHD 1
3 012953 PLUG, 3/4 NPT BI SQ HD PIPE 2
4 028915-10 SHIM, .010 LGE GEARBOX FLANGE 1
5 029146 KEY, GEARBOX SQ 1/2x2.5 1
6 037650 SHAFT, MAIN RH SHD GEARBOX 1
7 032745 PLUG, 1/8 NPT RED POLTHN THD 1
8 034541 FAN, SHD GEARBOX 1
9 029272 CUP, Ø3 TPR ROLLER BEARING 2
10 029150 CAP, SHD GEARBOX LARGE 1
11 028703 SHROUD, FAN GEARBOX SHD 1
12 029182 BEARING, Ø1.31 BORE TAPERED 1
13 029184 CUP, Ø3-43/64 TRP ROLLER BEARING 2
14 029178 BEARING, Ø1.43 BORE TAPERED 1
15 035327 PLUG, 3/4-14 NPTF HOLLOW HEX 1
16 029183 BEARING, Ø2 BORE TAPERED 2
17 010513 FITTING, 1/4-28 NPT STR GREASE 1
18 010091 WASHER, Ø3/8 ID Z-STL SPLIT LOCK 24
19 010038 BOLT, 3/8-16x1-1/2 GRADE 5 HEX HEAD CAP 12
20 029155 CAP, BOTTOM GEARBOX SHD 1
21 029180 SEAL, Ø1.875 RADIAL SHAFT OIL 1
22 032715 RING, Ø2.875 RETAINING 1
23 032716 BRACKET, SD GEARBOX 1
25 029147 FLANGE, GEARBOX SHD 1
26 010037 BOLT, 3/8-16x1-1/4 GRADE 5 HEX HEAD CAP 8
27 029181 SEAL, Ø1.125 RADIAL SHAFT OIL 1
28 029179 SEAL, Ø1.375 RADIAL SHAFT OIL 1
29 012869 SCREW, 1/4-20x3/8 BO SKT SET 1
30 015673 O-RING, 15/16x1-3/16x1/8 BUNA 1
31 018072 WASHER, NO. 10 Z-STL SAE FLAT 3
32 013740 WASHER, NO. 10 EXTERNAL-TOOTH LOCK 3
33 013484 SCREW, 10-24x1/2 ROUND PHILLIPS HEAD 3
34 015672 GAUGE, 3/4-14 NPT PORTHOLE VIEW 1
35 026154 CAP, SHD GEARBOX END 1
36 028914-10 SHIM, .010 LARGE GEARBOX COVER 1
37 028914-2 SHIM, .002 LARGE GEARBOX COVER 1
38 028915-5 SHIM, .005 LARGE GEARBOX FLANGE 1
39 001004 OIL, ALLEN MOBIL SHC 634 GEAR 0.75 2
40 029149 GEAR, 20:1 RH BRONZE 1
41 032713 RING, Ø1.827 RETAINING 1
42 032714 RING, Ø2.478 RETAINING 1
NOTES:
1. These shim thicknesses are established at the factory, call customer service for the appropriate replacement size.
2. QTY (U/M) is indicated by gallons.
