4-54
053430; 1/11
4.26 Parts List
Accessory - Pro Dolly Jack System
REF
PART NO. DESCRIPTION QTY NOTES
- 027684 SET, PRO DOLLY JACK 1 REF
1 017751 WASHER, 3/8 FLAT 16
2 010133 PIN, 3/16 X 2 COTTER 4
3 015692 CAP, 1/4 RED GREASE 4
4 010464 NUT, 3/8-16 NYLOCK LOCK 8
5 024628 SPACER, DOLLY JACK WHEEL 8
6 026728 ASSEMBLY, REAR DOLLEY TUBE [DASH NO. -02] 2
7 026729 ASSEMBLY, DOLLY JACK TUBE [DASH NO. -01] 2
8 026938 JACK, DOLLY 2
9 039633 DECAL, DOLLY JACK SYSTEM 2
10 040637 SCREW, 3/8-16 X 2-1/4 GRADE 8 HEX HD CAP 8
11 099014 ASSEMBLY, PNEUMATIC TIRE AND WHEEL 4
NOTES:
1. Not shown.
2. NOTE: Quantity values called out in QTY column above are for the set total. Dash -01
(REF NO. 6) and Dash -02 (REF NO. 7) required only half the value callout respectively.
