3-6
SECTION 3
SERVICE
053430; 01/11
FIGURE 3.3.2
BELT REMOVAL
TELESCOPING
U-JOINT
ASSEMBLY
DRIVEN PULLEY
COGGED VEE
CVT BELT
TORQUE CONVERTER
CLUTCH DRIVER
PULLEY
1/4-20x5/8 SOCKET HEAD RND
SCREWS (4X) AND Ø1/4 ID
SPLIT LOCK WASHERS (4X)
DRIVEN PULLEY
POSITION SPACER
CENTER SHAFT
HUB
3.3, continued
Drive Belt
