3-13
053430; 01/11
SECTION 3
SERVICE
3.6, continued
Lift Lever Adjustment
[A]
[B]
TROWEL ARM
BLADE
FIGURE 3.6.1
PRESSURE PLATE LOCATION
FIGURE 3.6.2
FASTENER HARDWARE REMOVAL
SPIDER BOSS
STABLIZER RING
