Section 4
PARTS
4.42 Parts List, Front View
Lower Frame Unit
REF
PART NO. DESCRIPTION QTY NOTES
- 048951 MODULE, MAIN FRAME 1
1 048838 FRAME, MSP425 MAIN 1
2 032097 DECAL, SERIAL NUMBER PLATE 1 1
3 012994 RIVET, 1/8x3/8 ALUM DOME HD 4 1
4 048906 TRAY F/ BATTERY, MAN TUBE 2
5 048946 FOOT REST, MSP425 1
6 049666 THROTTLE PEDAL ASS'Y 1
7 048932 BAR, BATTERY HOLD DOWN 1
8 042260 LATCH, FLEX DRAW LRG RUBBER 4
9 010568 SCR, 10-32 X 1/2 RND HD MACH 8
10 032358 WASHER, NO. 10 EXT TOOTH LOCK 8
11 048901 MOUNT, 250LB MOTOR MSP425 4
12 048559 BAR, BEARING HOUSING 4
13 048560 BEARING, Ø1 ID PLASTIC FLANGE 4
14 047547 FSTN, 5/16-18 PAL SNAP NUT 8
15 010082 WASHER, 5/16 SAE FLAT 7
16 010090 WASHER, 5/16 SPLIT LOCK 15
17 010019 FSTN, HHCS 5/16-18 X 3/4 GR 5 11
18 010100 FSTN, NUT HEX 5/16-18 8
19 010002 BOLT, 1/4-20x3/4 HEX HEAD CAP 11
20 010081 FSTN, FW 1/4 12
21 020542 FSTN, NUT STOVER LOCK 1/4-20 13
22 028243 CABLE, THROTTLE 52” HD 1 1
23 048977 NUT, 5/16-18 WING 2 1
24 012612 NUT, 5/16-18 NYLON HEX 4 1
25 010523 KEY, 3/16 SQ x 1-1/4 LG 1 1
NOTES:
1. Not shown.
