Section 4
PARTS
4.5 Parts List, Rear View
Lower Frame Unit
REF
PART NO. DESCRIPTION QTY NOTES
1 048354 GRIP, SAT 3 Ø1 BLACK HANDLE 1
2 047340 CAP, 1-1/2x1x1-4 BLK END 4
3 048913 GUARD, BELT MSP425 1
4 048906 TRAY F/ BATTERY, MAN TUBE 2
5 010090 WASHER, 5/16 SPLIT LOCK 15
6 010091 FSTN, LW 3/8 8
7 010036 FSTN, HHCS 3/8-16 X 1 8
8 042140 BRACKET, REAR LIGHT SP400B 2
9 010568 SCR, 10-32 X 1/2 RND HD MACH 8
10 012612 FSTN, NUT HEX NYLOCK 5/16-18 4
11 047547 FSTN, 5/16-18 PAL SNAP NUT 8 1
12 010082 WASHER, 5/16 SAE FLAT 7
13 010019 FSTN, HHCS 5/16-18 X 3/4 GR 5 11
14 048681 GROMMET, RUBBER 5/8 ID X 1-1/8 OD 1
NOTES:
1. Not shown.
