allen MSP445 - Page 80

4-20
053430; 1/11
4.8 Parts List
Steering System
REF
PART NO. DESCRIPTION QTY NOTES
1 010083 WASHER, 3/8 LOCK 1 1
2 010102 NUT, 3/8-16 HEX 1 1
3 060882 SHAFT, LONG STEERING LINKAGE 1
4 046701 ARM, STEERING 4-1/2 2
5 221408 ROD, END MALE 1/2 4
6 013740 WASHER, NO. 10 EXTERNAL TOOTH LOCK 4
7 048958 BOLT, 1/2-20x3-1/4 GR 8 HEX HEAD CAP 1
8
9 048896 STICK, STEERING MSP425 2
10 026267 BOLT, 3/8-16x1/2x1 SHOULDER 6
11 010464 NUT, 3/8-16 NYLOCK HEX 6
12 026447 NUT, 3/4-10 THIN SELF LOCKING HEX 4
13 010051 NUT, 1/2-20 FINE HEX JAM 6
14 010005 BOLT, 1/4-20x1-1/2 GRADE 8 HEX CAP 2
15 020542 NUT, 1/4-20 LOCK HEX STOVER 2
16
17 048969 SHAFT, STEERING 2 1
18 048970 SHAFT, FULCRUM 1 1
19 048925 FULCRUM, L/R STEERING MS 1
20 048894 CONTROL, RIGHT HORTIZONTAL 1
21 048895 CONTROL, RIGHT VERTICAL 1
22 048902 ASSY, 2-WAY STEERING 1
23 048869 ARM, LOWER CONTROL 2 1
24 048928 SHIM, FULCRUM STEEL 2.0 1,2
25
26 048929 BEARING, TFI-1214-16 IGL 12 1
NOTES:
1. Not shown.
2. QTY (U/M) is indicated by package.
