4.9 Parts List
Retardant Spray System
REF
PART NO. DESCRIPTION QTY NOTES
1 047700 TANK, 6 GALLON PLASTIC 1
2 048921 STRAP, TANK 2
3 012702 TIP, 80°x0.10 GPM BRASS SPRAY 2
4 048909 SWITCH, PUSH BUTTON 1 1
5 048910 BEARING, Ø5/8 NYLON FLANGED SLEEVE 1 1
6 047701 CAP, 3-1/2 VENTED BLACK 1
7 033735 PUMP, SPRAY SYSTEM 1
8 040209 FILTER, SPRAY SYSTEM 1
9 041604 BODY, NYLON CHECK VALVE NOZZLE 2
10 041606 NIPPLE, 1/4 NPT CLOSE PLASTIC 2
11 041624 RETAINER, NYLON SPARY TIP 2
12 047933 ELBOW, 1/4 PUSHLOK X 1/4 NPT PLASTIC 4
13 065244 SCREEN W/ CHECK VALVE (BLUE) 50 MES 2
14 012702 TIP, 80°x0.10 GPM BRASS SPRAY 2
15 047702 FITTING, “L” FUEL 1/4 NIPPLE 90° 1
16 047703 BUSHING, WATER TANK 1
17 016382 SCREW, 10-32x1 ROUND HEAD SLOT MACH 4
18 018072 WASHER, NO. 10 SAE FLAT 4
19 029568 NUT, 10-32 NYLOCK HEX 4
20 040387 ELBOW, 3/8x1/4 90° STREET BRASS 1
21 040388 FITTING, 3/8x1/4 BRASS FM-TO-FM REDUCER 1
22 048652 TEE, PLASTIC 1/4x1/4 1 1
23 010090 WASHER, 5/16 SPLIT LOCK 2
24 010100 NUT, 5/16-18 HEX 2
25 048246 HOSE, 3/8 WATER LINE 7.75 1,2
26 048959 GROMMET, 1/2 RUBBER HOSE 3 1
27 013557 BUSHING, 3/8 X 1/4 BRASS HEX 1
28 047520 ASSEMBLY, SPRAY NOZZLE - 3
NOTES:
1. Not shown.
2. QTY (U/M) shown in feet.
3. Includes Reference #’s: 3,9,10,11,13
