allen MSP455 - Page 103

052793 - 03/2013
SECTION 4
PARTS
Page 4-53
Electrical Schematics
Illustration
ACC
16 GA. BLACK 51" LG.
039162 5/16 EYELET
TERMINAL TO STARTER
1
1
"
1
1
"
COOLER FAN
G
H
7.5 FUSE AND
HOLDER
037817 3/8 EYELET
TERMINAL TO GROUND
1/4" SPLIT LOOM
MALE BULLET RECPT.
14-16 GA AWG
FEMALE BULLET CONNECTOR
14-16 GA AWG
FEMALE BULLET RECPT.
14-16 GA AWG
