052793 - 03/2013
SECTION 4
PARTS
Page 4-2
Factory Service Information
This section contains the illustrated drawings and parts list for help in identifying and/or ordering re-
placement parts for your machine. Follow the instructions in the front section of this manual “Ordering
Parts” when ordering replacement parts to insure prompt and accurate delivery.
The FRONT and/or REAR orientations are defi ned from the operator’s view of sitting on machine
(SOM).
All set screws have blue (LOC-TITE™) applied at the
factory. If set screw is removed or loosened for any
reason re-apply blue (LOC-TITE™).
All grease fi ttings are capped with CAP PLUG GC-5
(AEC PN 015692) to protect the fi tting. If cap becomes
missing or damaged replace it as soon as possible.
Anti-Seize is applied at the factory to drive line couplings,
and moving components. If these parts are disassembled re-
apply a light coat of a graphite based anti-seize.
