Engine Specifi cations
40 HP Kohler
MODEL CH1000
Weight 149.0 lbs
Engine Displacement (cc) 999
Start Type Electric
Engine Type Command Pro V-Twin OHV
Rated Power (HP) @ 3600 RPM 40
Torque (ft./lbs.) 61.5
Displacement (cu. in.) 61
Shaft Output Horizontal
Shaft Diameter (in.) 1 1/8
Shaft Length (in.) 4
Shaft End Tapped (Diameter (in.)/Threads per inch) 7/16–20
Compression Ratio 8.8:1
Cooling System Air cooled
Air Cleaner Type Heavy Duty
Fuel Type Gasoline
Fuel Filter In line
Oil Capacity (qt.) 2.9
Lubrication System Full pressure
Ignition System Electronic
Carburetor 2 Barrel Carb
Max. RPM 3,600
Charging System Amps 25
Muffl er Included Yes
EPA/CARB Approval (California Air Resource Board) Yes
