052793 - 03/2013
Page iv
Table of Contents - Continued
Title Page
Parts 4-1
Factory Service Information 4-2
Replacement Part Procedure 4-3
Seat Frame Assembly 4-4
Mainframe Assembly 4-12
Throttle Pedal Assembly 4-18
Kill Switch Pedal Assembly 4-20
Pitch Control Assembly 4-22
Right Hand (SOM) Rotor Assembly 4-24
Left Hand (SOM) Rotor Assembly 4-26
Left Gearbox Assembly 4-28
Right Gearbox Assembly 4-30
Right Hand Spider Assembly 4-32
Left Hand Spider Assembly 4-33
Spray System Assembly 4-34
Fuel System Assembly 4-36
Power Unit and Driveline Assembly 4-38
Steering Assembly 4-42
Hydraulics Assembly 4-46
Electrical Schematic 4-50
