allen MSP455 - Seat Frame Assembly

052793 - 03/2013
SECTION 4
PARTS
Page 4-5
Seat Frame Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
1 010001 FSTN, HHCS 1/4-20 X 1/2 GR 5 2
2 010002 FSTN, HHCS 1/4-20 X 3/4 8
3 010029 FSTN, HHCS 5/16-18 X 3-1/2 2
4 010081 FSTN, FW 1/4 2
5 010082 FSTN, FW 5/16 4
6 010089 FSTN, LW 1/4 8
7 010091 FSTN, LW 3/8 4
8 010098 FSTN, NUT HEX 1/4-20 8
9 010102 FSTN, NUT HEX 3/8-16 4
10 012612 FSTN, NUT HEX NYLOCK 5/16-18 2
11 029671 FSTN, NUT HEX 1/4-20 NYLOC 4
12 032125 ROCKER SWITCH 1
13 038979 DECAL, FWD-REV/LT-RT 1
14 038980 DECAL, FWD-REV 1
15 039048 DECAL, GEN PROTECTION WARNING 1
16 039778 DECAL, GREASE THRUST BEARING DAILY 1
17 041537 CUP HOLDER 1
18 042343 FSTN, SFBHCS 1/4”-20 x 3/4 9
19 045915 Jic(-6) to Male O-ring (-6), Straight 2
20 045921 FTG, F6400-8-8-O STR JIC-SAE 1
21 045922 FTG, F6400-4-6-O STR JIC-SAE 2
22 045928 FTG, F6400-4-4-O STR JIC-SAE 8
23 046736 CONTROL VALVE, RH DUAL AXIS 1
24 046777 FTG, F6400-6-4-O STR JIC-SAE 2
25 046892 FTG, 6801-6-6-NWO 90° ELB JIC-SAE 1
26 047052 RELAY, 12 V 30/50 A w/RES SHROUD 1
27 047665 BUMPER, RUBBER 3
28 047685 HOURMETER, SENDEC 807-204-0111 1
29 048181 DECAL, CALIFORNIA PRPSTN 65 1
30 048448 DECAL, AEC PATENT NUMBERS 1
31 048665 TUBE, MANUAL PACK PLASTIC 9000-14 1
32 049588 FEMALE RECEPTICAL 12VDC 1
33 049623 WELDT, JOYSTICK MOUNT PLATE - MSP460 2
34 052926 FTG, HYD SMK20-7/16UNF-VE TEST PORT 1
35 052932 DECAL, HALF SIZE MSP455 2
36 053189 U-BOLT, 3 1/2” X 3/8-16 2
37 053211 PROP F/ SEAT FRAME 1
38 053447 DECAL, HAND TOOL AREA (SP) 1
