allen MSP455 - Mainframe Assembly

052793 - 03/2013
SECTION 4
PARTS
Page 4-13
Mainframe Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
1 010001 FSTN, HHCS 1/4-20 X 1/2 GR 5 1
2 010002 FSTN, HHCS 1/4-20 X 3/4 8
3 010019 FSTN, HHCS 5/16-18 X 3/4 GR 5 8
4 010020 FSTN, HHCS 5/16-18 X 1 6
5 010035 FSTN, HHCS 3/8-16 X 3/4 8
6 010036 FSTN, HHCS 3/8-16 X 1 8
7 010037 FSTN, HHCS 3/8-16 X 1-1/4 GR 5 10
8 010073 FSTN, HHCS 1/2-13 X 2-1/2 GR 5 4
9 010081 FSTN, FW 1/4 16
10 010082 WASHER, 5/16 SAE FLAT 4
11 010083 FSTN, FW 3/8 6
12 010086 WSHR, Ø5/16 ID YZ STL SAE FLAT 2
13 010090 FSTN, LW 5/16 GRD8 10
14 010091 FSTN, LW 3/8 15
15 010100 FSTN, NUT HEX 5/16-18 6
16 010131 PIN, Ø1/16 X 1 ZP STL COTTER 1
17 010464 FSTN, NUT NYLOK 3/8-16 15
18 010568 SCR, 10-32 X 1/2 RND HD MACH 8
19 011490 FSTN, FW HARDENED 1/2 4
20 012612 FSTN, NUT HEX NYLOCK 5/16-18 12
21 012994 RIVET, 1/8x3/8 ALUM DOME HD 8
22 017751 FSTN, FW HARD A325 3/8 (p) 8
23 019430 FSTN, CLAMP SIZE 4 MINI 1
24 020542 FSTN, NUT STOVER LOCK 1/4-20 8
25 020604 CLIP, SAE 14-.406 INSUL LOOP 1
26 024984 PIVOT, THROTTLE CABLE 1
27 028243 CABLE, THROTTLE 52” HD 1
28 029568 NUT, 10-32 NYLOCK HEX 8
29 029671 FSTN, NUT HEX 1/4-20 NYLOC 1
30 029898 SPRING CLIP, FUEL FILTER 1
31 032097 DECAL, SERIAL NUMBER PLATE 2
32 032106 NUT, 5/16-18 STEEL LIGHT WING 2
33 032377 DECAL, F/ PITCH CONTROL TUBE 2
34 035597 INSULATOR, POS BATT TERMINAL 1
35 035598 INSULATOR, NEG BATT TERMINAL 1
36 036881 LIGHT, 12 V WORK 4
37 037771 BATTERY, 12 V GRAY 655CA 1
38 038174 RIDER MANUAL PITCH CONTROL ASSY 2
