allen MSP455 - Page 65

052793 - 03/2013
SECTION 4
PARTS
Page 4-15
Mainframe Assembly (cont’d)
Parts List
ITEM PART NO. DESCRIPTION QTY
39 039329 FSTN, CLIP TINNERMAN 1/4-20 4
40 040208 FSTN, 1/2-13 STOVER NUT 4
41 042140 BRACKET, REAR LIGHT SP400B 4
42 042260 LATCH, T-HANDLE EXTRA-LARGE DRAW 2
43 042343 FSTN, SFBHCS 1/4”-20 x 3/4 4
44 047273 CUSHION F/ BATTERY STRAP 1
45 047547 FSTN, 5/16-18 PAL SNAP NUT 4
46 047700 TANK, 6 GALLON WATER PLASTIC 1
47 047715 ROD, 5/16-18 BATTERY RETAINER 8-5/8” 2
48 048559 MNTG BLOCK, CROSSHEAD 4
49 048560 BEARING, Ø1 ID PLASTIC FLANGE 4
50 048901 MOUNT, 250LB, BLUE/WHITE 4
51 048906 TRAY F/ BATTERY, MAN TUBE 1
52 048921 STRAP, TANK 4
53 048932 BAR, BATTERY HOLD DOWN 1
54 052930 COOLER, AIR/OIL 2005K-12S-BP 1
55 053200 TANK, 6 GALLON W/ CAP (EPA) 1
56 053441 DECAL, LIFTING/CRUSH HAZARD (SP) 2
57 053442 DECAL, ALLEN VERTICAL BRUSHED CHROME 2
58 053443 DECAL, GASOLINE ONLY (SP) 1
59 053445 DECAL, RETARDANT ONLY (SP) 1
60 053446 DECAL, MADE IN USA (SP) 1
61 053448 DECAL, LIFT HERE ONLY (SP) 4
62 053449 DECAL, PINCH HAZARD (SP) 4
63 056470 BUSHING, NITRILE 2
64 056722 THROTTLE BRKT 1
65 056860 MAIN FRAME, MSP455 1
66 056888 UNDERCARRIAGE PAN 1
67 056907 BATTERY PLATE 1
68 059533 FOOT PEDAL W/ THROTTLE, RH 1
69 059535 FOOT PEDAL W/ KILL, LH 1
70 059544 FRONT COVER PLATE 1
71 059545 RISER F/ PLATFORM 1
72 060815 FRICTION TAPE, 4 X 10 1
73 060873 BELT STOP 1
