allen MSP455 - Page 71

052793 - 03/2013
SECTION 4
PARTS
Page 4-21
VISIT US!!!
www.alleneng.com
LIKE US!!! www.facebook.com/AllenEngineering
FOLLOW US!!! @alleneng
WATCH US!!!
www.youtube.com/AllenMachinery
Kill Switch Pedal Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
1 010002 FSTN, HHCS 1/4-20 X 3/4 4
2 010035 FSTN, HHCS 3/8-16 X 3/4 2
3 010082 FSTN, FW 5/16 1
4 015684 FSTN, NUT HEX JAM 3/8-16 4
5 024631 SWITCH, KILL FOR RIDING TROWEL 1
6 024840 PLATE, PEDAL FOOT SPEED 1
7 024851 THROTTLE HOUSING WMNT 1
8 026226 PIN, Ø3/32 X 3/4 ZP STL COTTER 1
9 028895 FSTN, PIN CLEVIS 3/8 X 3 3/4 1
10 041596 WELDMENT, KILL SWITCH PLATE 1
