allen MSP455 - Page 77

052793 - 03/2013
SECTION 4
PARTS
Page 4-27
Left Hand Rotor Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
1 010024 FSTN, HHCS 5/16-18 X 2 GR 5 15
2 010036 FSTN, HHCS 3/8-16 X 1 4
3 010090 FSTN, LW 5/16 15
4 010091 FSTN, LW 3/8 4
5 010095 FSTN, LW 5/8 8
6 010513 FITTING, 1/4-28 STR GREASE 1
7 012612 FSTN, NUT HEX NYLOCK 5/16-18 1
8 015677 RING, Ø7/16 E-STYLE RETAINING 2
9 015678 PIN, YOKE ARM 1
10 015691 FSTN, SHCS 1/2-13 X 1-1/2 RH 1
11 015692 CAP, Ø1/4 RED GREASE 7
12 015693 PLUG, PLASTIC CAP EC12 1
13 015694 PLUG W-1 RED PLASTIC TAPERD 5
14 015696 KEY, .25x1.25 LG HARD RAD 1
15 019969 FSTN, HHCS 5/8-11 X 1-3/4 4
16 020915 FSTN, HHCS 5/8-11 X 1-1/2 GR 5 4
17 025091 FSTN, 5/16-18x1/2xØ3/8x3/8 SHLDR SCR 5
18 025092 BUSHING, 3/8x1/2x5/16 BRONZE 5
19 026215 ARM, YOKE 1
20 026504 FSTN, SHLD BLT 3/8 X 1-1/4 1
21 029529 VALVE, RELIEF 1/8-27NPT (AIR V) 1
22 037532 BLADE, 8x18 FLAT FINISH GOLD 5
23 037652 WASHER, HD RETAINING 1
24 039685 BEARING, THRUST AXIAL BALL EW 1
25 039686 CAP, SHD PRESSURE PLATE 1
26 039687 PLATE, SHD PRESSURE 1
27 040794 ASSY, 1200-5-SHD LH SOM SPIDER 1
28 040833 RING, 1200VG SD 5 BL STAB 1
29 048881 WLDMNT, CROSSHEAD GB MNT 1
30 048966 CROSSHEAD, 2-WAY 1
31 056894 GEARBOX, 20:1 RATIO LH 1
32 201163 FITTING, 1/8-27 PTF STR GREASE 1
