052793 - 03/2013
SECTION 4
PARTS
Page 4-31
Right Hand Gearbox Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
1 010037 FSTN, HHCS 3/8-16 X 1-1/4 GR 5 8
2 010038 FSTN, HHCS 3/8-16 X 1-1/2 GR 5 8
3 010091 FSTN, LW 3/8 24
4 012869 FSTN, SHSS 1/4-20 X 3/8 1
5 012953 PLUG, 3/4 NPTF BI SQ HD PIPE 2
6 013484 FSTN, SCREW RHPMS 10-24 X 1/2 3
7 013740 FSTN, LW STAR #10 3
8 015672 GAUGE, 3/4-14 NPT PORTHOLE VIEW 1
9 015673 O-RING, 15/16x1-3/16x1/8 BUNA 1
10 018072 FSTN, FW #10 SAE 3
11 018510 FITTING, 1/4-28 NPT 45° GREASE 1
12 026775 FSTN, HHCS 3/8-16NC X 2 GR 8 8
13 028703 SHROUD, FAN GEARBOX SHD 1
14 028914-XX SHIM, (GENERIC) LGE GEARBOX CVR 1
15 029143 CASE, SHD GEARBOX 1
16 029144 SHAFT, COUNTER LH SHD 1
17 029146 KEY, GEARBOX SQ 1/2x2.500 2
18 029147 FLANGE, GEARBOX SHD 1
19 029150 CAP, SHD GEARBOX LARGE 1
20 029154 CAP, SHD GEARBOX END 1
21 029155 CAP, BOTTOM GEARBOX SHD 1
22 029178 BEARING, Ø1.4375 BORE TAPERED 1
23 029179 SEAL, Ø1.375 RADIAL SHAFT OIL 1
24 029180 SEAL, Ø1.875 RADIAL SHAFT OIL 1
25 029181 SEAL, Ø1.125 RADIAL SHAFT OIL 1
26 029182 BEARING, Ø1.3125 BORE TAPERED 1
27 029183 BEARING, Ø2 BORE TAPERED 2
28 029184 CUP, Ø3-43/64 TPR ROLLER BRG 2
29 029272 CUP, Ø3 TPR ROLLER BRG 2
30 032713 RING, Ø1.827 RETAINING 1
31 032714 RING, RETAINING Ø2.4780 1
32 032715 RING, Ø2.857 RETAINING 1
33 032745 PLUG, 1/8 NPT RED POLTHN THD 1
34 034541 FAN, SHD GEARBOX 1
35 035327 PLUG, 3/4-14 NPTF HOLLOW HEX 1
36 037651 SHAFT, MAIN LH SHD GEARBOX 1
37 048294 GEAR, 25:1 LH BRONZE 1
38 056870 CYL MNT WMNT, RH 1
