052793 - 03/2013
SECTION 4
PARTS
Page 4-35
Spray System Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
1 012702 TIP, 80°x0.10 GPM BRASS SPRAY 2
2 033735 PUMP, SPRAY SYSTEM 1
3 040209 FILTER, RETARDANT SPRAY SYSTEM 1
4 040387 ELBOW, 3/8 BRASS 90° STREET 1
5 040388 FTG, 3/8X1/4 BRASS FM TO FM REDUCER 1
6 041604 BODY, NYLON CHECK VALVE NOZ 2
7 041606 NIPPLE, 1/4 NPT CLOSE PLASTIC 2
8 041624 RETAINER, NYLON SPRAY TIP 2
9 047578 STRAINER, POLY 50 μ MESH 2
10 047700 TANK, 6 GALLON WATER PLASTIC 1
11 047933 ELBOW, 1/4 PUSHLOK x 1/4 NPT PLASTIC 3
12 048246 HOSE, 3/8” WATER LINE 7’
13 048652 TEE, PLASTIC 1/4 x 1/4 x 1/4 1
14 048653 BARB, HOSE PLASTIC 1/4” x 1/4 NPT 1
To Next Page
