allen MSP455 - Page 89

052793 - 03/2013
SECTION 4
PARTS
Page 4-39
Power Unit and Driveline Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
1 010020 FSTN, HHCS 5/16-18 X 1 2
2 010035 FSTN, HHCS 3/8-16 X 3/4 2
3 010037 FSTN, HHCS 3/8-16 X 1-1/4 GR 5 4
4 010082 FSTN, FW 5/16 2
5 010083 FSTN, FW 3/8 2
6 010084 FSTN, FW 7/16 1
7 010089 FSTN, LW 1/4 16
8 010090 FSTN, LW 5/16 2
9 010091 FSTN, LW 3/8 2
10 010092 FSTN, LW 7/16 1
11 010096 FSTN, Ø7/16 ID Y-ZINC HRDND FLAT 4
12 010102 FSTN, NUT HEX 3/8-16 2
13 010131 PIN, Ø1/16 X 1 ZP STL COTTER 1
14 010464 FSTN, NUT NYLOK 3/8-16 3
15 015692 CAP, Ø1/4 RED GREASE 8
16 015696 KEY, .25x1.25 LG HARD RAD 4
17 017314 SHCS, 1/4-20 X 5/8 16
18 017751 FSTN, FW HARD A325 3/8 (p) 1
19 017898 FSTN, HHCS 7/16-20 X 1-1/2 GR8 4
20 020514 FSTN, NUT STOVER LOCK 3/8-16 4
21 024820 STOCK, 1/4 SQx4 LG KEY 1
22 024984 PIVOT, THROTTLE CABLE 1
23 028243-1 CABLE, THROTTLE 52” HD 1
24 033661 PLATE, BELT GURD BKT. F/ BLM 1
25 039740 BOLT, 3/8-16 X 2-1/4 GR 8 HHC 4
26 042280 FSTN, HHCS 7/16-20 X 4 1/2 GR. 8 1
27 045921 FTG, F6400-8-8-O STR JIC-SAE 1
28 046550 PULLEY, AK30 X 1/2 BORE w/2SS 1
29 046738 HYD PUMP, AUX 1
30 046777 FTG, F6400-6-4-O STR JIC-SAE 1
31 046904 BEARING, Ø1 ID RCJT-1 FLANGE 2
32 047477 FSTN, 7/16-20 YZ GR “C” STOVER NUT 4
33 047635 HUB, Ø1 BORE U-JOINT CENTER SHAFT 4
34 047637 ASSY, U-JOINT TELESCOPING 2
35 048810 SPACER, BEARING MSP425 1
36 048845 SHAFT, DRIVE 1
37 048908 SPCR, 1.125 LG DRVN PUL POSN 1
38 048959 GROMMET, 1/2” RUBBER HOSE 2
