052793 - 03/2013
SECTION 4
PARTS
Page 4-41
Power Unit and Driveline Assembly
Parts List (cont’d)
ITEM PART NO. DESCRIPTION QTY
39 051332 BELT, CVT 1
40 052927 FTG, HYD F6502-8-8 1
41 053136 CLUTCH COVER, MSP445 1
42 053223 KEY, 3/16 X 1/4 X 2 1
43 053306 ENGINE, KOHLER CH-1000 1
44 053308 ENGINE PLATE WMNT 1
45
065967
CLUTCH
1
46 053385 THROTTLE BRKT 1
47 053389 PULLEY, MSP445, MP215 1
48 053444 DECAL, HOT W/ HAND 1
49 053453 DECAL, SPARK WARNING (SP) 1
50 056775 SHEAVE AK30x1-1/8 1
51 056906 ENGINE CONNECTING PLATE 1
52 056912 HYDRAULIC PUMP MOUNTING PLATE ASSEMBLY 1
53 056922 A22 HI-POWER V BELT 1
54 056938 HEAT SHIELD, 14”X20” 1
55 059513 SPACER F/ CLUTCH, MSP445 2
To Next Page
