SECTION 4
PARTS
4.7 Parts List
430 Edging Power Unit
ITEM PART NO. DESCRIPTION QTY
1 010002 FSTN, HHCS 1/4-20 X 3/4 20
2 010022 FSTN, HHCS 5/16-18 X 1 1/2" LONG 8
3 010081 FSTN, FW 1/4 16
4 010090 FSTN, LW 5/16 12
5 010100 FSTN, NUT HEX 5/16-18 4
6 010273 KEY, 3/16 SQ X 2 1
7 010464 FSTN, NUT NYLOK 3/8-16 4
8 012753 FSTN, LW 1/4 INT/EXT 4
9 012994 RIVET, 1/8x3/8 ALUM DOME HD 4
10 015202 GEARBOX, STD WALK BEHIND 1
11 015674 FSTN, STDBLT 3/8-16 X 1-3/4 4
12 015677 RING, Ø7/16 E-STYLE RETAINING 2
13 015678 PIN, YOKE ARM 1
14 015690 WASHER, RETAINING FOR TROWELS 1
15 015691 FSTN, SHCS 1/2-13 X 1-1/2 RH 1
16 015692 CAP, Ø1/4 RED GREASE 4
17 015693 PLUG, PLASTIC CAP EC12 1
18 015694 PLUG W-1 RED PLASTIC TAPERD 4
19 015696 KEY, .25x1.25 LG HARD RAD 1
20 015707 PULLEY, 3/4 BOREx5.73 OD V-GRV 1
21 015711 FSTN, FHSCS 3/8-16 x 3/4 4
22 015821 CAP, PRESSURE PLATE 1
23 015822 THRUST BEARING 1
24 015824 PLATE, PRO RIDER/WALKER PRESSURE 1
25 015987 GUARD BELT, SMALL PLASTIC 1
26 016191 DECAL, ALLOW ENG TO COOL 1
27 017264 YOKE, TROWEL 1
28 018012 FSTN, STD BLT 5/16-18 X 1-3/4 4
29 018961 ENGINE, HONDA 5.5 HP 1
30 020542 FSTN, NUT STOVER LOCK 1/4-20 16
31 020977 BRACKET, BELT GUARD MTG TW 1
32 020983 MUFFLER, HONDA 5.5 1
33 032097 DECAL, SERIAL NUMBER PLATE 1
34 032235 SPIDER ASSY, STD 750 LH (SOM) 1
35 032896 DECAL, MADE IN USA-FLAG 1
36 036665 SPACER, WB .25 LG CLUTCH 1
37 037262 RING, UPPER PT 430 EDGER 1
38 037263 RING, LOWER PT 430 EDGER 1
39 037265 ROLLER HOUSING FOR EDGERS 4
40 037266 SNAP RING 8
(Continued on Page 4-19)
