allen PRO 430 - Handle - 034284

4-45
055561; 01/12
SECTION 4
PARTS
4.15 Parts List
Handle - 034284
ITEM PART NO. DESCRIPTION QTY
1 010001 FSTN, HHCS 1/4-20 X 1/2 GR 5 1
2 010004 FSTN, HHCS 1/4-20 X 1-1/4 4
3 010075 FSTN, HHCS 1/2-13 X 3 GR 5 2
4 010089 FSTN, LW 1/4 4
5 010570 FSTN, NUT HEX 10-32 2
6 010572 FSTN, SCREW 8-32 X 3/8 1
7 011238 FSTN, NUT HEX NYLOK 1/2-13 2
8 013370 FSTN, RHMS 10-32 X 3/8 2
9 015735 THROTTLE CABLE ASSEMBLY - W/B 1
10 015739 KNOB, ADJUSTABLE HANDLE 1
11 015741 SCREW SHAFT, PITCH CONTROL 1
12 015742 THRUST BEARING 1
13 015743 BUSHING, F/ PITCH CONTROL 1
14 015744 WASHER FINE PITCH CNTRL SPACER 1
15 015746 BUSHING, SLIDE 1
16 015747 PIN, ROLL 3/16 X 1-3/8 SPIROL 1
17 015752 BLOCK, CABLE SUPPORT 1
18 015753 PULLEY, CABLE 1
19 015754 PIN 3/8 X 1 3/8 CABLE PULLEY 1
20 015768 FSTN, SHCS 1/4-20 X 1/4 HOLO 1
21 015769 BAR, CARRY F/ WALKBEHINDS 1
22 016691 CABLE PITCH CONTROL SHORT ASSY 1
23 018409 ASSY, SWITCH SAFETY COMPLETE 1
24 034279 BLOCK, CLAMP ADJ/HAND R/W 034277 1
25 034282 HANDLEBAR WDMT F/ADJ HNDL - PT 1
26 034286 EXTENSION WDMT F/SHT HNDL F/PT 1
27 034441 INSULATION, F/ HANDLEBAR 1
28 034714 BRKT, WB SHORT HANDLE FOOT PAD MTG 1
29 048308 GRIP, HANDLE (7/8"ID) 2
30 048379 DECAL, ALLEN 4 1/2 x 1 1/2 2
31 048937 DECAL, MFG BY ALLEN ENGR 1
32 049770 COVER, WB HANDLE PAD (STRAIGHT) 1
33 056336 DECAL AEC 1.5" X 3.25" WHITE/RED 1
