allen PRO 430 - 436 Edging Power Unit Parts List

4-21
055561; 01/12
SECTION 4
PARTS
4.8 Parts List
436 Edging Power Unit
ITEM PART NO. DESCRIPTION QTY
1 010002 FSTN, HHCS 1/4-20 X 3/4 20
2 010022 FSTN, HHCS 5/16-18 X 1 1/2" LONG 4
3 010024 FSTN, HHCS 5/16-18 X 2 GR 5 4
4 010081 FSTN, FW 1/4 16
5 010090 FSTN, LW 5/16 12
6 010100 FSTN, NUT HEX 5/16-18 4
7 010273 KEY, 3/16 SQ X 2 1
8 010464 FSTN, NUT NYLOK 3/8-16 4
9 012753 FSTN, LW 1/4 INT/EXT 4
10 012994 RIVET, 1/8x3/8 ALUM DOME HD 4
11 015202 GEARBOX, STD WALK BEHIND 1
12 015674 FSTN, STDBLT 3/8-16 X 1-3/4 4
13 015677 RING, Ø7/16 E-STYLE RETAINING 2
14 015678 PIN, YOKE ARM 1
15 015690 WASHER, RETAINING FOR TROWELS 1
16 015691 FSTN, SHCS 1/2-13 X 1-1/2 RH 1
17 015692 CAP, Ø1/4 RED GREASE 4
18 015693 PLUG, PLASTIC CAP EC12 1
19 015694 PLUG W-1 RED PLASTIC TAPERD 4
20 015696 KEY, .25x1.25 LG HARD RAD 1
21 015707 PULLEY, 3/4 BOREx5.73 OD V-GRV 1
22 015711 FSTN, FHSCS 3/8-16 x 3/4 4
23 015821 CAP, PRESSURE PLATE 1
24 015822 THRUST BEARING 1
25 015824 PLATE, PRO RIDER/WALKER PRESSURE 1
26 015893 SPIDER ASSY, 900-SFC LH-SOM 1
27 015987 GUARD BELT, SMALL PLASTIC (5.5 HP) 1
015703 BELT GUARD, LARGE PLASTIC (9 HP) 1
28 016191 DECAL, ALLOW ENG TO COOL 1
29 017264 YOKE, TROWEL 1
30 018012 FSTN, STD BLT 5/16-18 X 1-3/4 4
31 018961 ENGINE, HONDA 5.5 HP 1
042481 ENGINE, HONDA 9 HP 1
32 020542 FSTN, NUT STOVER LOCK 1/4-20 16
33 020977 BRACKET, BELT GUARD MTG TW 1
34 020983 MUFFLER, HONDA 5.5 1
35 032097 DECAL, SERIAL NUMBER PLATE 1
36 032896 DECAL, MADE IN USA-FLAG 1
37 036665 SPACER, WB .25 LG CLUTCH 1
38 037265 ROLLER HOUSING FOR EDGERS 4
39 037266 SNAP RING 8
40 037267 BEARING, FOR EDGER ROLLER 8
(Continued on Page 4-23)
