www.alliancelaundry.com

START

25

C

HIG

H

T

E

MP

MED

TEMP

L

OW

T

E

MP

NO

HE

A

T

1

2

3

SELECT

TE

M

P

I

N

S

ER

T

CO

I

N

P

US

H

S

T

A

R

T

T463PE1A

Tumble Dryers

25 Pound (220 liter)

30 Pound Stack (300 liter)

30 Pound (270 liter)

35 Pound (350 liter)

Refer to Page 5 for Model Numbers

Part No. 70143101R3

November 2016

Service

Table of Contents

Questions and Answers:

T
tinawilliamsAug 16, 2025
Why won't the burner ignite on my Alliance Laundry Systems JT0300DRG?
- H
  hkingAug 16, 2025
  If the burner on your Alliance Laundry Systems Dryer isn't igniting, several issues could be the cause. Check for blown fuses or a tripped circuit breaker, ensure the gas shut-off valve is open, and verify sufficient gas supply and pressure. Also, inspect for lint buildup, proper ductwork, and adequate make-up air. The drying selector should not be set to the “Cool Down” portion of the cycle. Other potential causes include incorrect orifices, wiring issues, a faulty airflow switch, inoperative cabinet thermostat, or problems with the IEI control or motor switch. The lint drawer/panel must be closed properly. Refer to the Installation Instructions for exhaust system and make-up air requirements.
V
Veronica GloverAug 22, 2025
What to do if burners are not burning properly on Alliance Laundry Systems JT0300DRG Dryer?
- D
  David MaxwellAug 22, 2025
  If the burners on your Alliance Laundry Systems Dryer are not burning properly, check for dirt in the burners and clean them if necessary. Ensure the gas pressure is correct according to the rating plate and that the correct orifices are installed. A restricted or blocked exhaust duct, a malfunctioning airflow switch, or inadequate make-up air could also be the cause. Refer to the Installation Instructions for make-up air requirements.
C
Craig EdwardsAug 26, 2025
What causes the burner to not shut off on Alliance Laundry Systems JT0300DRG?
- J
  James BrownAug 26, 2025
  If the burner on your Alliance Laundry Systems Dryer does not shut off, it could be due to impurities on the gas valve seat, preventing the valve from closing, in which case the gas valve should be replaced. Incorrect wiring could also be a cause. Refer to the wiring diagram.
J
Justin EllisAug 28, 2025
Why don't my clothes dry in my Alliance Laundry Systems JT0300DRG?
- B
  Brittany WilcoxAug 28, 2025
  Several factors can prevent your Alliance Laundry Systems Dryer from properly drying clothes. Ensure you're allocating enough heating time, and that the drying selector is appropriately set. Reduce the load size if it's too large (the maximum load is 25 lb dry weight for a 25 lb dryer). Also, make sure there isn't too much water in the clothes before drying. Check for a blocked exhaust duct or a clogged lint screen, and ensure the exhaust damper isn't binding. Other potential issues include an inoperative thermistor, burner problems, incorrect voltage, or inadequate make-up air. Refer to the Installation Instructions for exhaust system and electrical requirements.
P
pleonardAug 31, 2025
Why does the motor overload protector cycle repeatedly on my Alliance Laundry Systems JT0300DRG?
- U
  uatkinsonAug 31, 2025
  If the motor overload protector in your Alliance Laundry Systems Dryer cycles repeatedly, it could be due to several reasons. The clothes load might be too large, or the cylinder could be binding. Check for correct voltage and adequate wiring, and ensure there's sufficient make-up air. Lint buildup around the dryer and motors can also cause this issue, as can broken, loose, or incorrect wiring. Refer to the Installation Instructions for electrical and make-up air requirements.
M
Mark DorseySep 3, 2025
Why is my Alliance Laundry Systems JT0300DRG Dryer overheating?
- C
  cynthia37Sep 3, 2025
  If your Alliance Laundry Systems Dryer is overheating, it could be due to several factors. Ensure the correct main burner orifices are installed and that the gas pressure is properly adjusted. Check for lint buildup and ensure the exhaust system is not restricted or inadequate. Also, make sure there is adequate make-up air and that the exhaust damper is not binding. An inoperative thermistor sensor could also be the cause. Refer to the Installation Instructions for make-up air and exhaust system requirements.
D
Daniel LittleSep 6, 2025
What to do if motor runs but cylinder does not turn in Alliance Laundry Systems JT0300DRG?
- M
  Mr. Kirk MyersSep 6, 2025
  If the motor in your Alliance Laundry Systems Dryer runs but the cylinder doesn't turn, the cylinder belt may be broken and needs replacement. Another possible cause is that the cylinder is binding, so check the cylinder for any obstructions.
D
David BakerSep 9, 2025
Why does the motor not stop in my Alliance Laundry Systems Dryer?
- J
  Jorge RodgersSep 9, 2025
  If the motor in your Alliance Laundry Systems Dryer does not stop, it could be due to an inoperative door switch or lint drawer switch, which should be tested and replaced if faulty. An inoperative coin drop or a malfunctioning electronic control could also be the cause. Incorrect wiring may also be responsible. Refer to the wiring diagram.
C
cindy64Sep 10, 2025
Why does the burner ignite and go out repeatedly on my Alliance Laundry Systems JT0300DRG?
- P
  Patricia NashSep 12, 2025
  If the burner in your Alliance Laundry Systems Dryer ignites and then goes out repeatedly, it could be due to insufficient gas pressure, an inoperative cabinet thermostat, or an improper or inadequate exhaust system. Improper orifices, broken, loose, or incorrect wiring, excessive igniter to burner clearance, or inadequate make-up air could also be the cause. Refer to the Installation Instructions for exhaust systems and make-up air requirements.
W
wolfeclintonSep 12, 2025
What to do if cylinder door opens during operation of Alliance Laundry Systems JT0300DRG Dryer?
- K
  Kelsey SmithSep 12, 2025
  If the cylinder door on your Alliance Laundry Systems Dryer opens during operation, it may be due to the dryer being improperly leveled. Also, an excessive load in the dryer can cause this issue; remove part of the load and restart the dryer.

Alliance Laundry Systems JT0300DRG Specifications

General

Brand	Alliance Laundry Systems
Model	JT0300DRG
Category	Dryer
Language	English

Summary

Safety Information

Safety Warnings and Decals

Highlights important safety warnings and decals placed on the machine.

Troubleshooting

TUMBLE DRYER DOES NOT START

Addresses issues where the tumble dryer fails to start operation.

MOTOR DOES NOT START

Troubleshooting steps for when the motor does not begin running.

MOTOR OVERLOAD PROTECTOR CYCLES REPEATEDLY

Diagnosing frequent cycling of the motor overload protector.

MOTOR RUNS BUT CYLINDER DOES NOT TURN

Resolving issues where the motor runs but the cylinder remains stationary.

MOTOR DOES NOT STOP

Troubleshooting the condition where the motor fails to stop.

BURNER DOES NOT IGNITE

Steps to diagnose why the burner fails to ignite.

BURNER IGNITES AND GOES OUT REPEATEDLY

Addresses intermittent burner ignition and shutdown issues.

BURNER DOES NOT SHUT OFF

Diagnosing the problem of the burner not shutting off as expected.

CLOTHES DO NOT DRY

Solutions for the appliance not drying clothes effectively.

TUMBLE DRYER OVERHEATING

Troubleshooting steps for excessive dryer temperatures.

BURNERS NOT BURNING PROPERLY

Diagnosing and correcting improper burner combustion.

CYLINDER DOOR OPENS DURING OPERATION

Resolving issues where the cylinder door unexpectedly opens.

Grounding

Grounding Instructions

Essential guidelines for correctly grounding the tumble dryer for safety.

Service Procedures

DOOR SWITCH (ALL MODELS)

STOVE HIGH LIMIT THERMOSTAT

COMPLETE GAS VALVE ASSEMBLY

Detailed instructions for removing and replacing the entire gas valve assembly.

IGNITER ASSEMBLY

ELECTRONIC IGNITION CONTROL

HEATER ELEMENT (Electric Models)

Adjustments

LEVELING LEGS

Guide to adjusting the dryer's legs for stability and proper leveling.

CYLINDER DOOR SWITCH

Instructions for adjusting the door switch to ensure proper dryer shutdown.

CYLINDER DOOR STRIKE
