Specifications and Dimensions
F232135
14
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
For 40 and 50 Pound Capacity Variable-Speed
and Fixed-Speed Machines
Figure 5
CHM2000N
1 Sump 3 Vibration Switch
2 Gap Distance 4 Switch Extension
1
2
3
4
3
4
