Specifications and Dimensions
15
F232135
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
For 60 Pound Capacity Variable-Speed and
Fixed-Speed Machines
Figure 6
CHM1999N
1 Lower Bracket 4 Balance Bolt
2 Upper Bracket 5 Lock Nut
3 Vibration Switch 6 Gap Distance
CHM1999N
6
2
2
4
3
5
1
