NOTE: For 80 and 125 pound models, a
bolt-locator fixture or rebar frame is available as
an option. This is designed to be embedded in
concrete. Refer to Figure 10.
IMPORTANT: Do not install any variable-speed
machine on an elevated base frame.
Figure 10
P035I
1 Machine Base
2 Mounting Bolt Threads
3 Grouting
4 Bolt-Locator Fixture or Rebar Frame
1
2
3
4
