ALLIANCE SWNNY2SP115TW01 User Manual

• Press the START (enter) keypad to diplay Diagnostic Test options.
• Press the DELICATES or the COLD keypad to scroll through the Diagnostic Test options.
• To enter a test, press the START (enter) keypad.
• To exit a test, press the WARM keypad.
"d 1"
Control Software
Version Number Test
"d 2"
Input/Output Board
Software Version # Test
"d 8"
Service Door Switch
Input Test
"d 9"
Coin Vault Switch
Input Test
"dIAg"
Diagnostic Tests
"d 10"
Coin Drop #1
Input Test
"d 11"
Coin Drop #2
Input Test
"d 12"
Vend Connection Header
Present Input Test
"d 13"
Start Pulse
Input Test
"d 15"
Lid Switch
Input Test
"d 17"
Show Fill
Time Test
TLW51R_SVG
"d 18"
Show Drain
Time Test
"d 23"
External Output Test
"d 24"
Water Purge Test
"d 26"
Water Level Test
"d 29"
Machine Configuration #1
Display Test
"d 25"
Water Leak
Detection Test
"d 30"
Machine Configuration #2
Display Test
"d 31"
Machine Configuration #3
Display Test
"d 32"
Machine Configuration #4
Display Test
"d 33"
Machine Configuration #5
Display Test
Figure 12
Testing Machine and Electronic Control Functions
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
72 Part No. 204370ENR1
