Network Adapter Card Installation Guide
105
3. Select Allied Telesyn Multi-Vlan Support Protocol then select
Properties.
4. The window shown in Figure 91 is displayed.
Figure 91 VLAN Setup Window (1 of 2)
5. Select the VLAN to be removed.
6. Select Remove. It may take Windows a few moments to renumber
the adapter driver.
When completed, the window shown in Figure 92 is displayed.
Figure 92 VLAN Setup Window (2 of 2)
The desired VLAN has been removed.
7. Select OK.
The Local Area Connection Properties window is displayed.
8. Select OK.
To remove additional VLANs, repeat this procedure.
