Chapter 1: Network Adapter Card Overview
28
LEDs Table 7 describes the LEDs on the AT-2700FTX and AT-2701FTX Series
adapter cards. The twisted pair port uses either the 10 or 100 LED,
depending on its operating speed. The fiber optic port uses just the 100
LED.
BootPROM Chip and MBA Feature
AT-2700FTX Series Optional
AT-2701FTX Series Standard
Default Port 100Base-FX
Load Balancing and Fail-over Protection
AT-2700FTX Series Not supported
AT-2701FTX Series
Supported
2
Default setting: Disabled
1. Numerous factors, such as too many splices or poorly implemented splices,
can significantly reduce the maximum distance of a fiber optic port. Fiber optic
cable should only be installed by a qualified fiber optic cable contractor.
2. Microsoft Windows 2000, 2003, and XP.
Table 6. AT-2700FTX and AT-2701FTX Series Network Adapter
Cards (Continued)
Table 7. AT-2700FTX and AT-2701FTX Series LEDs
LED Status Description
10 Green The twisted pair port
is operating at 10
Mbps, full-duplex
mode.
Amber The twisted pair port
is operating at 10
Mbps, half-duplex
mode.
Flashing The twisted pair port
is receiving or
transmitting network
packets at 10 Mbps.
