LEDs Table 9 describes the LEDs on the AT-2745FX and AT-2746FX Series
adapter cards. The 10Base-FL port uses the 10 LED and the 100Base-FX
port uses the 100 LED.
Table 9. AT-2745FX and AT-2746FX Series LEDs
LED Status Description
10 Green The 10Base-FL port
is operating at 10
Mbps, full-duplex
mode.
Amber The 10Base-FL port
is operating at 10
Mbps, half-duplex
mode.
Flashing The 10Base-FL port
is receiving or
transmitting network
packets at 10 Mbps.
100 Green The 100Base-FX port
is operating at 100
Mbps, full-duplex
mode.
Amber The 100Base-FX port
is operating at 100
Mbps, half-duplex
mode.
Flashing The 100Base-FX port
is receiving or
transmitting network
packets at 100 Mbps.
