Network Adapter Card Installation Guide
51
Installing a Network Adapter Card
This section explains how to install a network adapter card in most
PC-compatible systems. Refer to system’s instruction manual for specific
information on installing peripheral devices.
Note
The optional BootPROM chip for an AT-2450FTX, AT-2700FX,
AT-2700FTX, or AT-2745FX Series card should be installed before
the card is installed in the system. For instructions, go to “Installing a
BootPROM Chip” on page 200.
To install the network adapter card, perform the following procedure:
1. Shutdown your system and disconnect the power cord from the outlet.
Warning
High voltage inside the system presents a safety hazard. Make sure
the power is off before removing the cover.
2. Remove the system’s cover by removing the screws from the chassis
and gently sliding off the cover. See Figure 5.
Figure 5. Removing the PC Cover
